Beoremote Halo

Types: 1624, 1625, 2067, 6014
Batteries: 3 x AA
Dimensions: 25,4 x 3,8 x 2,0cm
Weight with batteries: 290g
Beo4 part number: 1162411 (EU)
Beo4 Wall bracket (Type 2067) part number: 1206766


Source Change
Old names, hard sources New names, hard sources
V.TAPE V.MEM
A.TAPE A.MEM
SAT DTV
Old name, soft sources New names, soft sources
V.TAPE2 DVD2
P-V.TP2 P-DVD2
L-V.TP2 L.DVD2
A-V.TP2 A-DVD2
CAMCORD CAMERA
DOORCAM V.AUX2
A.TAPE2 A.MEM2
New soft sources
P-V.AU2
Deleted soft sources
PHONE
CD2

New Features
New features Description
P.MUTE Picture mute, toggle function that blanks picture
LOCK Manual record lock
UNLOCK Manual record unlock
VIDEO4 configuration Enables P-AND-P as default for the B-chassis
Old Feature Name: New feature name
P-I-P P-AND-P

Most recent S/W 4.2


Beo4 configuration
to set the Beo4 to work with specific products,
i.e. Avant, BS9000.

The Beo4 with SAT, V.TAPE and A.TAPE buttons displays
MX, AV9000, AVANT, AV5 and NONE as video options.
BASIC and BS9000 as audio options.

There are also Beo4 versions with the same buttons that have numeric options.
For example a 2003 version with software EE: 6.0 SW: 5.0
has Video 1 to 3 and Audio 1 and 2.

The Beo4 with DTV, V.MEM and A.MEM buttons has numeric options.
Video 1 to 4 and Audio 1 and
